IntroductionMy kid is a fan of The IT Crowd, so it didn't surprise me when I received the following bug report:
Hey Dad. My computer was acting funny. So, I just turned it off for awhile. Just letting you know.My kid's desktop runs the following servers to collect and export machine measurements:
- Prometheus Collectd Exporter
On another machine, I run Prometheus to collect, store, and analyze my measurements. I wondered if I can use Prometheus debug what happened.
Up or DownI would like to learn when the machine got turned off. Prometheus uses HTTP to collect metrics from the target machine. If Prometheus can finish this scrape, it stores a 1 in a time series named UP -- a failed scrape will get a value of 0. I learned two things:
- The computer was turned off at 02:00.
- The computer failed a scrape two hours earlier! This means Prometheus was unable to use http to collect metrics from the Collectd Exporter target. Very odd.
DashboardI customized the existing prometheus console templates to work with collectd's plugins. This makes it easier to view the common machine metrics in one spot. I discovered the following from that machine's dashboard:
- At one point, all the CPU and RAM were in use -- this was when the Prometheus HTTP scrape failed.
- The machine went idle for two hours.
- There was a spike before the machine was powered off. I am guessing my kid used the soft power off button and didn't unplug the computer from the power outlet.
